Convert floor plan images into clean, editable DXF drawings.
Choose the options below, text recognition starts after image upload
Conversion Type
Convert Image to DXF with AI
Convert image to DXF in seconds — upload a PNG, JPG, or JPEG floor plan and get a clean, editable drawing back. Our AI recognizes walls, doors, windows and room boundaries as real objects, then writes each to its own CAD layer so the file opens perfectly in AutoCAD, Revit, SketchUp, or Blender.
From Any Image to a Clean, Layered DXF
Not a pixel trace — whether you need png to dxf, jpg to dxf, or a quick image converter to dxf for any picture to dxf, our AI understands the floor plan and writes a structured, layer-separated CAD file you can actually edit.
4 Named CAD Layers
Every conversion is split into four named layers — Walls, Doors, Windows, and Rooms — instead of a single flat line layer. Toggle, re-color, and select each category instantly in your CAD software.
- ✓Walls / Doors / Windows / Rooms on separate layers
- ✓Clean, named layer structure for easy editing
- ✓No merged polylines or garbage geometry
AI Semantic Recognition, Not Tracing
Traditional raster tracers dump every pixel into one tangled line layer. Our engine detects walls, doors, windows, and room boundaries as structured objects, so your DXF is a real drawing — not a messy scan — and remains fully editable downstream.
- ✓Walls, doors, and windows become editable CAD entities
- ✓Room boundaries detected and labeled automatically
- ✓Same accuracy for png to dxf, jpg to dxf, and bmp to dxf conversions
The Universal Exchange Format
DXF is the industry-standard interchange format for CAD. One file works across AutoCAD, Revit, SketchUp, Blender, LibreCAD, QCAD, and CNC / laser-cutting tools — no vendor lock-in, no conversion headaches. Once your DXF is ready, you can convert your 2D floor plan to 3D for a walkable preview.
- ✓Opens natively in AutoCAD and Revit
- ✓Imports cleanly into SketchUp, Blender, LibreCAD
- ✓Text-based format, future-proof and portable
Enhance & Straighten
Turn on Enhance to correct perspective, straighten walls, and denoise scans from phone photos. Low-contrast PNG screenshots and compressed JPG scans both clean up well, so the result is a crisp, technical-looking DXF without the artifacts of the original shot.
- ✓Perspective correction for phone photos
- ✓Line straightening and denoising
- ✓Keep raw mode for hand-drawn sketches
Auto Dimension Annotations
Add wall lengths, room areas, and overall dimensions in one click — switch between Feet and Meters without regenerating. Hand off a measured DXF straight to a contractor or permit office.
- ✓Wall lengths and room areas annotated automatically
- ✓Feet or Meters — switch instantly
- ✓Ready for permits and contractor handoffs
Bulk-Friendly Workflow
Real estate agents and renovation contractors can convert multiple listings in a session. Each conversion is saved to your project history, and you can re-export any plan in a different format without re-uploading. Starting from scratch? Generate a floor plan first, then run it through this converter.
- ✓Convert multiple scans per session
- ✓Re-export any saved plan as DXF without re-uploading
- ✓Version history keeps every variant safe
Convert PNG or JPG to DXF in Seconds
Got a floor plan sitting in your screenshots folder or buried in an old email? You don't have to re-draw it. Upload the file and our AI recognizes the walls, doors, windows, and rooms, then writes each one to its own CAD layer — you download a clean, editable DXF in seconds. Both formats run through the same engine, so png to dxf and jpg to dxf give you identical, layer-separated output. JPEG to DXF, BMP to DXF, and photo to DXF conversions follow the same workflow.
PNG to DXF is the highest-frequency scenario. Screenshots from listing sites, exported CAD viewports, and web-clipped plans are almost always PNG — while scanned blueprints and phone photos land as JPG. Whichever you have, this is where most renovations and permit submissions begin.
Convert your PNG or JPG to DXF
How to Convert Image to DXF
From a PNG, JPG, or JPEG to a clean, layered DXF in three easy steps.
Upload Your Image
Upload a PNG, JPG, JPEG, or BMP (up to 15 MB). Screenshots, photos, scanned blueprints, and hand-drawn sketches all work.
AI Recognizes the Layout
Our AI detects walls, doors, windows and room boundaries, then sorts each into its own CAD layer — no manual tracing.
Download Your DXF
Get a clean, layered DXF with Walls, Doors, Windows, and Rooms on separate layers — ready to open in AutoCAD, Revit, SketchUp, or Blender.
Why Choose Our Image to DXF Tool
Turn any scan into a structured, layer-separated DXF — built for CAD, design, and on-site capture workflows.
Named CAD Layers
Walls, Doors, Windows, and Rooms land on separate layers — no flat, merged-line output.
Multi-Format Input
png to dxf, jpg to dxf, screenshots and scans up to 15MB — no pre-processing required.
Dimension Annotations
Add wall lengths and room areas in one click — switch Feet and Meters without regenerating.
Universal Export
One file works across AutoCAD, Revit, SketchUp, Blender, LibreCAD and CNC tools.
Image to DXF FAQ
Common questions about DXF, layers, accuracy, credits, and privacy.
What is DXF and why should I use it?
What image formats are supported?
Does the output use separate layers?
Which software can open my DXF file?
How many credits does it cost?
Is my uploaded image private?
How do I convert a PNG or JPG to DXF?
Can I convert a JPG or PNG to DXF?
Ready to Convert an Image to DXF?
Upload any floor plan image and get a clean, layered DXF in seconds.
Explore More Floor Plan Tools
Generate plans, convert formats, and explore 3D models.
